Metalforming Fluids

Metalforming operations like pressing, stamping, deep drawing, wire drawing, tube drawing and forging require specially formulated compounds to assist in the process. During these operations considerable amount of heat and stress are generated and this is where ACS' Drawing Compounds are designed to perform.

Characteristic of deep drawing is the high pressure—on the order of 100,000 pounds per square inch (PSI)—involved in the operation. The tooling and sheet metal surfaces are pressed so tightly together that the liquid is squeezed out and only a very thin adsorbed film remains. This film forms a "boundary," preventing direct metal-to-metal contact under conditions of high pressure and temperature produced during the deep drawing operation. Proper lubrication prevents friction, which causes heating and can ultimately lead to the breakdown of a lubricant.

Omega Draw 130AVLX drawing metalforming compound oil
OMEGA DRAW 130AVLX
A synthetic metalforming compound with esters and weeding agents designed to be used in a variety of materials including galvanized metals.


Omega Draw 440-70P drawing metalforming compound oil
OMEGA DRAW 440-70P
Used in metalforming for auto-frenetic parts and medium duty processes.
​

Omega Draw 917 drawing metalforming compound oil
OMEGA DRAW 917
A heavy duty metal forming product designed for steel forming. Works in progressive dies and can be roll coated on material. Chlorinated water extendable product. Use at 20-1 up to 1-1

Omega Draw 918 drawing metalforming compound oil
OMEGA DRAW 918
A very heavy duty water soluble drawing compound with additive to aid in cleaning the product off parts in a spray washer.

Omega Draw 920 drawing metalforming compound oil
OMEGA DRAW 920
A synthetic drawing and punching product.

​

Omega Draw 2931-B drawing metalforming compound oil
OMEGA DRAW 2931 B
A a heavy duty drawing compound for steel and some aluminum. It helps eliminate galling and premature die life.
It can be sprayed, wiped or roll coated.

Omega Draw LV drawing metalforming compound oil
OMEGA DRAW LV
Heavy duty straight oil for ferrous metals and deep draws. Will perform on heavy duty punches ans extend tool and die life over competitive products. Polar ingredients with extreme boundary lubrication.

Omega Draw NC drawing metalforming compound oil
OMEGA DRAW NC
Non chlorinated straight oil.
